ESP32-WROOM-32UE-N8R2 Multiprotocol WiFi Bluetooth Module 2.4GHz 8MB Flash

ESP32-WROOM-32UE-N8R2 Multiprotocol WiFi Bluetooth Module 2.4GHz 8MB Flash

★ ★ ★ ★ ★
4.8 recensioni verificate
€32,00 EUR
€32,00 EUR
Sale

Calcolo della spedizione in corso...

Taxes included. Shipping calculated at checkout.

  • 24h Express Shipping
  • Secure Payments
  • Satisfied customers

Free annual check-up included with every Ipertech purchase

ESP32-WROOM-32UE-N8R2 - WiFi & Bluetooth Multiprotocol Module by Espressif Systems

The ESP32-WROOM-32UE-N8R2 module integrates the ESP32-D0WD-V3 chip with superior stability and security. It is an ideal solution for IoT, automation, wireless device, and embedded applications requiring 2.4GHz WiFi and Bluetooth 4.2 LE connectivity.

Main Features

  • Integrated chip: ESP32-D0WD-V3 with dual-core Xtensa core
  • Dual-mode connectivity: WiFi 2.4GHz (802.11 b/g/n) + Bluetooth 4.2 LE
  • Flash Memory: 8MB built-in
  • PSRAM: 2MB for high memory applications
  • Data rate: up to 150 Mb/s
  • Output power: 19.5 dBm
  • Receiver sensitivity: -97 dBm (Bluetooth) / -88 dBm (WiFi)
  • Multiple interfaces: I2C, I2S, PWM, SDIO, SPI, UART
  • Compact size: 18mm x 19mm x 3.2mm
  • External antenna for maximum installation flexibility

Complete Technical Specifications

Producer Espressif Systems
Manufacturer code ESP32-WROOM-32UE-N8R2
Series ESP32-WROOM-32UE
Category Multi-protocol modules
Core Xtensa dual-core
Operating frequency 2.4 GHz
WiFi Protocol 802.11 b/g/n
Bluetooth Protocol Bluetooth 4.2 LE (BLE)
Flash Memory 8 MB
PSRAM 2 MB
Data rate 150 Mb/s
Output power 19.5 dBm
WiFi Sensitivity -88 dBm
Bluetooth Sensitivity -97 dBm
Modulation DPSK, DQPSK
Interfaces I2C, I2S, PWM, SDIO, SPI, UART
Power supply voltage 3.0V - 3.6V
Operating current 500 mA (max)
Operating temperature -40°C to +85°C
Antenna type External (U.FL connector)
Assembly PCB Mount (SMD)
Shielding Unshielded
Dimensions 18mm x 19mm x 3.2mm
Sensitive humidity Yes (MSL)
RoHS Compliant

Typical Applications

  • IoT devices and smart homes
  • Industrial automation and building automation
  • Wearable devices and fitness trackers
  • Wireless Gateways and Network Bridges
  • Remote control systems
  • Wireless sensors and data loggers
  • Audio streaming and multimedia devices
  • Maker projects and rapid prototyping

Advantages of the ESP32-WROOM-32UE Module

Based on the ESP32-D0WD-V3 chip, this module offers improved stability and security over previous versions. Combining WiFi and Bluetooth in a single compact module reduces cost, design complexity, and PCB space.

With 8MB of Flash and 2MB of PSRAM , the module supports complex applications and OTA (Over-The-Air) firmware. Multiple interfaces (SPI, I2C, UART, I2S, PWM, SDIO) ensure maximum flexibility in integrating with sensors, displays, external memories, and peripherals.

Note: Images are for reference only. Always consult the official spec sheet for complete specifications.
